The larger Victron SmartSolar MPPT controllers handle serious solar arrays, up to 100A of charge current and 250V PV input. They suit off-grid homes, big caravan and truck setups, marine and commercial systems. They have the same proven MPPT tracking and Bluetooth as the smaller models, plus an optional plug-in display and VE.Can networking on most models.
Reading the model name: in 100/30, the first number (100) is the maximum PV open-circuit voltage in volts, and the second (30) is the maximum battery charge current in amps. Make sure your panels' cold-weather open-circuit voltage stays below the first number, and pick a charge current that suits your array size and battery bank.
Tr, MC4 and VE.Can
- Tr: PV and battery cables into screw terminals inside a wiring compartment.
- MC4: PV connects with standard MC4 solar connectors (multiple strings), with no need to open the case for the array.
- VE.Can: adds VE.Can ports for daisy-chaining multiple controllers and connecting to a GX device. It's good for large multi-controller systems. All models also have VE.Direct and Bluetooth.
Key features
- Ultra-fast MPPT tracking with partial-shade optimisation.
- Bluetooth monitoring and setup through VictronConnect.
- Optional pluggable display (sold separately).
- Battery voltage: 12/24/36/48V auto-select (48V must be set manually on some models).
- Programmable relay and remote on/off.
- VE.Smart Networking, plus Cerbo GX / VRM remote monitoring.
PV arrays at these voltages must be installed by a licensed electrician.
| Brand | Victron |
|---|---|
| SKU / Part No. | SCC115060211 |
| Category | Solar Charge Controllers |
| Weight | 3.0 kg |
| Max PV voltage options | 150V, 250V |
| Charge current options | 60A, 70A, 85A, 100A |
| Connection options | Tr, MC4, Tr VE.Can, MC4 VE.Can |
| Availability | Special Order — call (07) 4052 1901 |
